Whelen 9052055 - Manual (Page 2)

Page 2
2
1
3
4
5
6
7
1
1
1
1
4
4
1
ITEM PART NUMBER DESCRIPTION
MODEL 9052055 (IRIDITE / 14V) UPPER
ASSY, 14V LED ANTI COLLISION LIGHT 90520
14V PIGTAIL, 16"
GASKET, LENS
LENS, CLEAR LED ANTI-COLLISION HARDCOAT
ADAPTER, MTG LED A/C BEACON MODEL 90520
WASHER, #4 LOCK-SPRING MS35338-135
SCREW, 4-40 X 5/16 PPHMS MS51957-14
0 1 - 0 7 9 0 5 2 0 - 5 5
0 1 - 0 2 9 0 5 2 2 - 5 0
4 6 - 0 7 5 0 8 9 8 - 0 1
3 8 - 0 2 5 0 8 8 5 - 0 0
6 8 - 4 9 7 1 0 8 2 A 3 0
0 7 - 5 7 1 3 6 1 - 1 0 0
1 6 - 0 0 5 0 5 0 6 1 3 5
1 4 - 0 0 5 0 5 0 5 - 1 4
QTY
2
3
4
5
6
7
1
Suggested Mounting Hole Pattern
115°
TOP
115°
FRONT 130°
3X 6-32 Mounting Holes
6-32 x 5/16 suggested
screw length
Heli-Coil Insert
(3)
