Alignment Tool ” window will popup.
Set the target RSSI (e.g. -70dBm) and click “Start” button.
Wait about 5 seconds, the antenna alignment starts and performs alignment every one second.
Fix the local antenna and adjust the remote antenna elevation and horizontal direction. During
the adjustment, observe “Current RSSI” in local WAP-7500. The value will refresh every 1 second.
Fix the remote antenna when it reaches your expectation. Usually, RSSI between -60 and -70dBm
indicates rather good signal strength.
Adjust the local antenna after fixing the remote one. During the adjustment, observe “Current
RSSI ” in the remote WAP-7500. Fix the local antenna when it reaches your expectation.
When the antenna alignment tool starts, the WAP-7500 will issue beep sound to indicate current
RSSI. Once the tool is closed the WAP-7500 will stop beeping. Frequency of beep indicate the
following RSSI:
Table 3 RSSI-Beep Frequency
RSSI Beep Frequency
>-50 100 /sec
-50~-60 50 /sec
-60~-70 5 /sec
-70~-80 2 / sec
-80~-90 1 /sec
< -90 No beep sound
