Chapter 1 Introduction
Thank you for purchasing WNRT-625. This manual guides you on how to install and properly use the
WNRT-625 in order to take full advantage of its features.
1.1 Package
Contents
Make sure that you have the following items:
•
WNRT-625 x 1
•
Ethernet Cable x 1
•
Power Adapter x 1
•
CD-ROM (included user’s manual) x 1
•
Quick Installation Guide x 1
If any of the above items are missing, please contact your supplier for support
1.2 Features
z
IEEE 802.11n wireless technology compliant with 802.11b/g standard
z
Capable of up to 300Mbps data rate
z
Supports Wi-Fi Protected Setup (WPS)
z
Supports 64/128-bit WEP, WPA –TKIP(PSK), WPA2-AES(PSK), 802.1x
z
AP / Station-Infrastructure / Bridge (WDS) / Repeater modes supported
z
Equipped with four LAN ports (10/100M) and one WAN port (10/100M), Auto-MDI/MDI-X
supported
z
Supports DHCP Server
z
System status monitoring includes Active DHCP Client, Security Log and Device/Connection
Status
z
Web-based GUI for and Wizard setup for easily configuration
z
Remote Management allows configuration and upgrades from a remote site
z
Supported Internet types: Dynamic / Static IP / PPPoE / PPTP / L2TP
z
MAC / IP filter access control, URL blocking ; SPI firewall + DoS prevention protection
z
Supports UPnP function
1.3 Specification
Standard
IEEE 802.11b/g, 802.11n Draft 2.0, IEEE802.3u
Frequency range
2.4 ~ 2.4835GHz
Radio Technology
IEEE 802.11b: DQPSK, DBPSK, DSSS, and CCK
IEEE 802.11 g: BPSK, QPSK, 16QAM, 64QAM
IEEE 802.11n: MCS0~MCS7
WAN Port
1 x 100Base-TX, Auto-MDI/MDI-X
LAN Port
4 x 100Base-TX, Auto-MDI/MDI-X
Antenna connector
2 x Fixed 2dBi Dipole Antenna
Data Encryption
64 bit / 128 bit WEP, WPA-PSK, WPA, WPA2, 802.1x encryption
Frequency
2.400GHz - 2.483GHz
Output Power
802.11b: Typ. 18dBm@Normal Temp Range;
802.11g: Typ. 15dBm@Normal Temp Range;
802.11n: Typ. 15dBm@Normal Temp Range.
