Software
UR24C Operation Manual 11
MASTER Area
This is the area for configuring the master channel
settings.
Level Meter
Indicates the signal level.
Loop Back
Turns the Loopback function on (lit) and off (unlit).
MIX
Monitor mode DAW
Indicates the volume balance status of the input signal
adjusted with the [MIX] knob on the device and the output
signal from software such as a DAW.
Monitor mode DJ
Adjust the volume balance between the input signal and
the output signal from software such as a DAW.
Output Area
This section indicates the output signal level of the Output
area.
Level Meter
Indicates the signal level.
MIX Area
This section indicates the MIX object. It is normally set to
on.
What is Loopback?
Loopback is a convenient function for broadcasting
over the Internet. It mixes the input audio signals (such
as microphone and guitar) with the audio signals
playing back in the software in the computer into two
channels in the UR24C, and sends them back to the
computer. Refer to the section “Signal Flow” (
page 34 ).
If the Loopback function is on while you are monitoring
input signals from the UR24C via DAW software, it will
cause loud noise. This is because an infinite loop of the
audio signal is generated between the UR24C and the
DAW software. When using the loopback function, turn
off the monitor functions on your DAW software.
Monitor mode DAW Monitor mode DJ
UR24C
BGM Deliver
