Software
UR24C Operation Manual 12
Meter Window
This window is for showing the meter at the top of the Main
window.
Level Meter
Indicates the signal level. Peak hold is normally set to on.
Setup Window
This window is for configuring the common settings of the
device.
Device
Selects the device when simultaneously connecting one
or more devices that are capable with dspMixFx UR-C.
Device Settings
Opens the Control Panel.
HPF Setting
Selects the cutoff frequency of the high pass filter.
Options: 120 Hz, 100 Hz, 80 Hz, 60 Hz, 40 Hz
Monitor Mode
Switches the mode settings.
Options: DAW, DJ
Zoom
Changes the window size.
Options: 100%, 150%, 200%, 250%, 300%
Knob Mode
Selects the method of operating the knobs on dspMixFx
UR-C.
About
Indicates the version of the firmware and software.
Display color Description
Green Up to 18 dB
Yellow Up to 0 dB
Red CLIP
Settings Description
Circular Drag in a circular motion to increase and
decrease the parameter. Drag on a dial
clockwise to increase, and counterclockwise
to decrease. If you click any point on the
knob, the parameter will jump there instantly.
Linear Drag in a linear motion to increase and
decrease the parameter. Drag upward or
rightward to increase, and downward or
leftward to decrease. Even if you click any
point on the knob, the parameter will not jump
there.
