Software
UR24C Operation Manual 14
Effect Settings area
This area is used to set parameters related to the UR24C
input/output port effects.
Pre/Post
Used to select the insertion point for the effect.
Effect Name
Displays the names of the applied effects.
Effect Bypass
Enables/bypasses the effect.
Effect Edit
Displays the Effect Edit window.
Effect Type
Selects the effect type.
Settings: No Effect, Morphing Ch Strip ([m] or [s]), GA Classics -
CLEAN, GA Classics - CRUNCH, GA Classics - LEAD,
GA Classics - DRIVE
NOTE
The maximum number of Channel Strip and Guitar Amp Classics
iterations which can be used simultaneously is limited. Refer to
the “Limitations on the Use of Effects” (
page 33 ).
REV-X Send
Adjusts the signal level which is sent to REV-X.
Range: -∞ dB – +6.00 dB
REV-X Name
Displays the selected REV-X type.
REV-X Edit
Opens the “REV-X” ( page 18 ) setup window.
REV-X Type
Selects the REV-X type.
Settings: Hall, Room, Plate
Outputs area
This area is used to set parameters related to hardware
outputs.
Output name
Displays the output name of the hardware output.
Output meter
Displays meters for the hardware Mix Bus connected to
hardware outputs.
Meter Clip
Displays the output meter clip when clipping occurs. Click
this to stop this display.
