12
3. Turn Parameter knob 2, and select “Off”.
4. Press the LIVE button to exit GLOBAL mode.
TIP Settings in GLOBAL mode are saved automatically.
Quick Start
Playing/stopping a pattern (Live mode)
When this unit is turned on, it first enters this state (Live mode). Press the LIVE but -
ton to return to this state. If you are unsure about operations, try pressing this button.
1. Press the (PLAY) button to play the pattern and the rhythm.
2. Use buttons 1 to 13 to play each part, or turn the TEMPO knob to change the tempo.
3. Press the (PLAY) button again to stop the pattern.
TIP Press the (PLAY) button while holding down the SHIFT button to
pause. To resume from Pause mode, press the (PLAY) button while
holding down the SHIFT button again.
Selecting a program
EXPAND SHRINK GROOVE
QUEUE QUEUE
GLOBAL
CLEAR ALL AUDIO IN CHOKE RAND.PART CLEAR PART COPY PART SYNC POLY RAND.PART CLEAR PART
PATTERN KIT MOTION
CLEAR ALL ON/OFF CLEAR STEP CLEAR PART CLEAR ALL INIT
SP 2 ATTACK
DECAY SP 2
TUNE SP 2 DETUNE HT
TUNE HT
DECAY HT
DRIVE
DECAY
SNAPPY
DECAY CH DECAY
OH DECAY TUNE
VOLUME
TUNE
DECAY
HYBRID DRUM MACHINE
drumlogue
16 32
YES NO
8 TRIP.
BD SD HT OH RS CP SP 1 SP 2 MULTI CH LT
1 3 R L/MONO
AUDIO OUT
DC 9V
TEMPO
PAGE
PROGRAM KIT
PATTERN EDIT
IN OUT TO DEVICE TO HOST
BASS DRUM SNARE DRUM HIGH HATS SAMPLE 1/2 TOMS
CLAP
2 4
AUDIO IN
IN OUT
ANALOG DIGITAL MULTI EFFECTS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
MIDI SYNC
ATTACK SP 1
DECAY SP 1
TUNE SP 1 DETUNE
TUNE
DECAY LT
LT
LT
DELAY BD SD HT CH RS CP SP 1 SP 2 VPM NOISE USER REVERB MASTER
SHIFT
PART
OH
SELECT SAVE SELECT SAVE
LT
LIVE
MUTE
ACCENT LOOP STEP MOTION CHAIN TIME > <
>
<
2 2
1, 3
1. When you press the PROGRAM SELECT button, it enters the standby state
to load a program, and the PROGRAM SELECT button blinks.
2. Turn Parameter knob1&4, and select a program that you want to load.
TIP You can also select 16 programs in the same BANK by pressing the corre-
sponding buttons 1 to 16.
3. When you press the PROGRAM SELECT button again, the program will be
loaded.
