46
INDIV. OUT1 (Button 4)
OUT 1 [BD, SD, LT, HT, CH, OH, RS, CP, SP1, SP2, MULTI]
Sets the part to be output from the AUDIO OUT1 jack on the rear panel.
OUT 2 [BD, SD, LT, HT, CH, OH, RS, CP, SP1, SP2, MULTI]
Sets the part to be output from the AUDIO OUT2 jack on the rear panel.
OUT 3 [BD, SD, LT, HT, CH, OH, RS, CP, SP1, SP2, MULTI]
Sets the part to be output from the AUDIO OUT3 jack on the rear panel.
OUT 4 [BD, SD, LT, HT, CH, OH, RS, CP, SP1, SP2, MULTI]
Sets the part to be output from the AUDIO OUT4 jack on the rear panel.
INDIV. OUT2 (Button 5)
MUTE 1 [OFF, ON]
Turn this ON to mute the part output to the AUDIO OUT1 jack from the AUDIO
OUT L/MONO, AUDIO OUT R, or headphone output.
MUTE 2 [OFF, ON]
Turn this ON to mute the part output to the AUDIO OUT2 jack from the AUDIO
OUT L/MONO, AUDIO OUT R, or headphone output.
MUTE 3 [OFF, ON]
Turn this ON to mute the part output to the AUDIO OUT3 jack from the AUDIO
OUT L/MONO, AUDIO OUT R, or headphone output.
MUTE 4 [OFF, ON]
Turn this ON to mute the part output to the AUDIO OUT4 jack from the AUDIO
OUT L/MONO, AUDIO OUT R, or headphone output.
MIDI ROUTING (Button 7)
CH [1...16, 1-12, 2-13...5-16, 6-1..16-11]
Sets the MIDI channel used for MIDI sending/receiving. In addition to single chan -
nels 1 to 16, you can assign 11 parts to different MIDI channels ( → p.57 "MIDI
Implementation Chart").
ROUTE [USB+MIDI, USB]
MIDI signals can be sent and received via the MIDI and USB connectors, or by the
USB connector alone.
USB+MIDI : MIDI messages are received via the USB B connector and the MIDI IN con -
