36
USER
SOUND SELECT
SELECT [---, Nano, ...]
Select the user synth to load.
At the time of shipment from the factory, the user synth "Nano" developed in col -
laboration with Sinevibes is installed on this unit.
TIP Parameters vary depending on the user synth. For explanations about
functions other than nano, refer to the manual for each user synth.
PARAMETERS * For Nano
NOTE [C-1...C5]
Sets the sound pitch.
WAVE [2x Saw, 2x Sqr, 2x Tri, Saw+Sqr, Saw+Tri, Sqr+Tri, Ring 1..3]
Select the waveforms of two oscillators.
DETUNE [-24.0...+24.0]
Adjusts the pitch shift between the main oscillator and the sub oscillator.
BALANCE [0%...100%]
Adjusts the volume balance between the two oscillators.
FILTER [LP, HP, BP]
Select the filter type. There are three types of filters: low pass, high pass, and band pass.
CUTOFF [0%...100%]
Adjusts the cutoff frequency of the filter.
KEYTRACK [0%...100%]
Adjusts the key tracking effect on the filter cutoff.
RESON (RESONANCE) [0%...100%]
Adjusts the cutoff resonance of the filter.
EG TYPE [D, A1D, A2D]
Select the type of EG (Envelope Generator).
D : Type with the fixed attack and adjustable decay only
A1D : Adjusts the attack and decay at the same time. The attack time and decay
time are the same.
A2D : Adjusts the attack and decay at the same time. The decay time is twice the
length of the attack time.
