LED control-panel view
1
3
2
5 4 6
9
7
8
10
Table 1-3 LED control-panel view
Number Item Description
1 Control panel LED display This screen displays error codes and numerical information for copy jobs.
2 Up arrow button Use this button to increase the value that appears on the display.
3 Down arrow button Use this button to decrease the value that appears on the display.
4 Start Color Copy / Resume
button Press this button to start a color copy job.
5
Start Mono Copy button
Press this button to start a mono copy job.
6
Copy Setup button
Use this button to navigate through the Number of Copies, Lighter/Darker, and
Reduce/Enlarge options. The default option is Number of Copies.
7 Cancel button Press this button to perform the following actions:
● Cancel a print job when the printer is printing.
● Reset the current copy settings to the default values when the printer is idle.
● Exit Copy Default Setting mode without saving the value when the printer is in
Copy Default Setting mode.
8 Attention LED The Attention light blinks when the printer requires user attention, such as when the
printer runs out of paper or a toner cartridge needs to be changed. If the light glows
without blinking, the printer has experienced an error.
9 Ready LED The Ready light glows without blinking when the printer is ready to print. It blinks
when the printer is receiving print data or canceling a print job.
10 Supplies LEDs A Supplies light blinks when a supply error occurs, and it glows without blinking when
the supply is very low and replacement is required.
