3. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
4. Enter the switch password.
The default password is
password
. The password is case-sensitive.
The Switch Information page displays.
5. Select VLAN
.
The Basic Port-based VLAN Status page displays.
6. If this is the first time that you are accessing this page or if you are changing the
VLAN assignment method, select the
Enable
radio button and continue with Step
7.
Otherwise, see Step 9.
A pop-up window opens, informing you that the current VLAN settings will be lost.
7. Click the OK
button.
The pop-up window closes.
8. Click the Apply
button.
Your settings are saved.
The VLAN Configuration and VLAN Membership sections display.
9. In the
VLAN Identifier
menu, select the VLAN.
10. Select the ports that you want to add to the VLAN by doing the following:
a. (Optional) In the
Group Operation
menu, select either
Select All
or
Remove
All
.
All ports are either added to the VLAN or removed from the VLAN.
b. Select or remove individual ports by selecting the check boxes that are associated
with the port numbers.
Note:
If ports are members of the same LAG, you must assign them to the same
VLAN.
c. Click the
Apply
button.
Your settings are saved. In the VLAN Membership table, the ports display as
members of the VLAN.
11. To select ports for another VLAN, repeat Step 9 and Step 10.
