The login page displays.
4. Enter the switch password.
The default password is
password
. The password is case-sensitive.
The Switch Information page displays.
5. Select
VLAN > 802.1Q > Advanced > VLAN Configuration
.
The Advanced 802.1Q VLAN Status page displays. The menu on the left displays
more options.
6. Select
VLAN Membership
.
You can select
VLAN Membership
only if you already enabled the advanced 802.1Q
VLAN option (see Create 802.1Q-Based VLANs in an Advanced Configuration on
page 34).
The VLAN Membership page displays.
7. In the VLAN ID
menu, select the VLAN.
8. Select the ports that you want to add to the VLAN by doing the following:
a. (Optional) In the
Group Operation
menu, select
Untag All
,
Tag all
, or
Remove
all
.
All ports are either added to the VLAN (tagged or untagged) or removed from
the VLAN.
b. Select individual ports and assign them as tagged (T) or untagged (U) ports or
remove individual ports by selecting the check boxes that are associated with
the port numbers.
By default, all ports are untagged.
c. Click the
Apply
button.
Your settings are saved. In the VLAN Membership table, the ports display as
members of the VLAN.
9. To select ports for another VLAN, repeat Step 7 and Step 8.
10. To verify your selections, select VLAN > 802.1Q > Advanced > VLAN Configuration
.
The Advanced 802.1Q VLAN Status page displays. In the VLAN Identifier Setting
table, the ports display next to the VLAN or VLANs to which they were added.
