Front Panel
Figure 2. Front panel
The following table lists the front panel components from left to right.
Table 1. Front panel components
Description Letter
Power LED A
Factory Defaults
button (see Use the Factory Defaults Button to Reset the Switch on page 69)
B
Eight RJ-45 Gigabit Ethernet ports numbered 1 through 8 that support 1G, 100M, and 10M C
Two RJ-45 10-Gig/Multi-Gig Ethernet ports numbered 9 and 10 that support 10G, 5G, 2.5G, 1G,
and 100M D
For information about the status LEDs, see Status LEDs on page 9.
User Manual 8 Hardware Overview of the
Switch
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS110EMX
