Manage the OUI Table
The switch includes default Organizationally Unique Identifiers (OUIs), which are
associated with VoIP phones of specific manufacturers. All traffic received on voice
VLAN ports from VoIP phones with a listed OUI is forwarded on the voice VLAN.
You can add and remove OUIs. The maximum number of OUI entries in the table is 15.
The first 3 bytes of the MAC address contain a manufacturer identifier, while the last 3
bytes contain a unique station ID. You must add an OUI prefix in the format AA:BB:CC.
To manage the OUI table:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that
is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
4. Enter the switch password.
The default password is
password
. The password is case-sensitive.
The Switch Information page displays.
5. Select VLAN > Voice VLAN > OUI Table
.
The OUI Table page displays.
6. Take one of the following actions:
• To add an OUI prefix to the table, do the following:
a. In the Telephony (OUIs)
field, enter an OUI in the format AA:BB:CC.
b. In the Description
field, enter a description with a maximum of 32 characters.
c. Click the Add
button.
The OUI is added to the table.
• To delete one or more OUI prefixes from the table, do the following:
a. Select one or more OUIs.
b. Click the
Delete
button.
The OUIs are removed from the table.
