A-61981 20 April 2022 7
Rear view
1 Printer port — allows connection from the Kodak Printer Accessory to
the scanner.
2 USB port, type A — connects the scanner to an accessory flatbed.
3 USB port, type B — connects the scanner to the PC.
4 Ethernet port — connects the scanner to the network.
5 Power port — connects the adapter power cord to the scanner.
6 Back panel — removable to allow you to attach the Kodak Printer
Accessory.
7 Rear document exit — allows you to exit exception documents from the
rear of the scanner.
8 Rear document exit toggle — toggle this switch to enable the straight-
through paper path option of the scanner which will allow exception
documents to exit through the rear document exit. To close the rear exit,
push down on the toggle switch until it clicks into place.
9 Security lock port — connects a security lock to the scanner. You can
purchase a standard security lock at an office supply store. Refer to the
instructions provided with the security lock for installation procedures.
8
6
5
2
1
3 4 7
9
