7. PARAMETER PAGES
30
have any phasing issues. A value of 1 tells that the signal is fully in mono. A negative value is a sign that
the low band audio has problems with phasing.
BASS Sets if the low band part of the signal should be in stereo or mono.
XFREQ Crossover frequency sets the frequency of the crossover filter.
LP LEV Sets the attenuation of the low band part of the signal.
HP LEV Sets the attenuation of the high band part of the signal.
7.3.7 CHORUS
The chorus can be used to widen sounds, enhance the stereo image or add subtle movement to sounds.
DEPTH Depth sets the depth of the LFO modulation of the chorus.
SPEED Speed sets the speed of the LFO modulation of the chorus.
WIDTH Width sets the stereo width of the chorus.
MIX Sets the mix between the clean signal and the signal that is affected by the effect.
7.3.8 DELAY PAGE 1
The delay send effect takes the input signal, delays it in time and then adds it to the original signal.
TIME Delay Time sets the delay time. The delay time settings are relative to the current BPM and is mea-
sured in 128th notes.
TIME setting Divide ratio
1 1/128
2 1/64
2.67 1/48 (1/32T)
3 1/64.
4 1/32
5.33 1/24 (1/16T)
6 1/32.
8 1/16
