10. TECHNICAL INFORMATION
40
10. TECHNICAL INFORMATION
ELECTRICAL SPECIFICATIONS
Impedance balanced audio outputs
Main outputs level: +19 dBu
Output impedance: 440 Ω unbalanced
Headphones output
Headphones out level: +19 dBu
Output impedance: 36 Ω
Balanced audio inputs
Input level: +19 dBu peak
Audio input impedance: 39 kΩ
Control inputs
Input level on tip: -5 V–+5 V. Supplies +5 V on ring
Accepts CV, Expression pedals, Footswitches
Unit power consumption: 12 W typical
Recommended power supply: PSU-3/b/c,
12 V DC, 2A
HARDWARE
128 × 64 pixel OLED screen
MIDI In/Out/Thru with DIN Sync out
2 x 1/4” impedance balanced audio out jacks
2 x 1/4” balanced audio in jacks
1 x 1/4” stereo headphone jack
2 x 1/4” control input jacks
48 kHz, 24-bit D/A and A/D converters
Electrically isolated Hi-speed USB 2.0 port
Power inlet: Center positive 5.5 x 2.5 mm barrel jack,
12 V DC, 2A
PHYSICAL SPECIFICATIONS
Sturdy steel casing
Dimensions: W 215 x D 184 x H 63 mm (8.5” x 7.2” x
2.5”) (including power switch, jacks, knobs and feet)
Weight: approximately 1.5 kg (3.3 lbs)
100 x 100 mm VESA mounting holes. Use M4
screws with a max length of 7.4 mm.
Maximum recommended ambient operating
temperature: +35˚C (+96˚F)
