Chapter 3 OSD Menu
The switcher’s OSD menu allows the user to perform several configurations of video effects, such as
picture-in-picture, luma key, etc. The user can also configure the audio settings in the Audio sub menu.
The setup sub menu allows the user to set video output resolution, reset to factory default, and select
the interface language.
3.1 Start
Main Sub-Menu Options or Values Default Value
Start
Transition Type
MIX
WIPE Mix
Transition Speed 1-200 frames
60 frames; the duration in
second depends on the Program
OUT resolution.
WIPE Effect
Left Right
Top Bottom
Center Left Right
WIPE Border Size
OFF
Small
Middle
Large Small
WIPE Border Color
White
Yellow
Cyan
Green
Magenta
Red
Blue
Black Red
BKG Color
White
Yellow
Cyan
Green
Magenta
Red
Blue
Black White
WIPE Rev.
Normal
Rev Normal
Transition Type
The SHOWCAST 100 provides two types of transition effect, which are cross dissolve (MIX) and WIPE.
The default setting is MIX.
Transition Speed
The Transition Speed allows the user to set the MIX or WIPE effect duration, in frames. If the Transition
Speed is set to a value of 60 then the transition will take effect over a period of 1 second if the
