84

In the Latency field, enter the amount of latency to apply to the stream. The default value is
1000 ms.
b. If Listener is selected, simply enter a port number that you intend to use on this device for the
SRT stream.
3. Click the Start Stream button to start the SRT stream.
6.4 Record/Stream Panel
The RECORD, STREAM, VERTICAL and BITRATE buttons on the front panel of the SHOWCAST 100 give
the user certain controls of the record and stream functions. In this section, we will cover operations
of these four buttons in detail.
The table below summarizes the RECORD and STREAM Button LED behaviors:
RECORD Button STREAM Button
Solid White Record function in idle state Stream function in idle state
Blinking Red Record function is activating or resetting Stream function is activating or resetting
Solid Red Record function activated Stream function activated
Record Button
Press the RECORD button to start/stop recording.
Start recording

When idle, the RECORD button is solid white.

Press and hold the RECORD button for approximately 2 seconds.

When the record function is activating, the RECORD button turns from solid white, then
blinking red and finally to solid red.

When the RECORD button is solid red, this indicates that the record function has been
successfully activated.
Stop recording

While recording, the RECORD button is solid red.

Press and hold the RECORD button for approximately 2 seconds.

When the record function is terminating, the RECORD button turns from solid red, then
blinking red and finally to solid white.

When the RECORD button is solid white, this indicates that the record function has been
successfully terminated.
