29
Main Sub-Menu Options or Values Default Value
PIP/Split
PIP Source
Black
Input 1
Input 2
Input 3
Input 4
Background
Color Bar Input 2
PIP Size 1-100% 30%
Position X -50% - +50% 20%
Position Y -50% - +50% 10%
Split Source
Black
Input 1
Input 2
Input 3
Input 4
Background
Color Bar Input 2
Border Size
OFF
Small
Middle
Large Small
Border Color
White
Yellow
Cyan
Green
Magenta
Red
Blue
Black Red
PIP/SPLIT Mode
PIP
Split PIP
PGM ON/OFF OFF
PVW ON/OFF OFF
PIP Source
Select a PIP source from the list below:

Black

Input 1

Input 2

Input 3

Input 4

Background

Color Bar
PIP Size (PIP Window Size)
The PIP window size ranges from 1 to 100 with 1% being the smallest and 100 being the largest.
Therefore 50% would represent a PIP window which is half the size of the background image. 100%
would see the PIP window totally cover the background image unless offset to one side.
