22
31-7000138 Rev. 0
Remove 2 screws on top of oven, just above
the grille panel, using a Phillips screwdriver.
Open the door.
Remove the grille. Slide the grille to the left then
pull out.
Insert the filter into the oven as shown until it fits
squarely into place. It will rest at an angle behind
the front lower tabs. When properly installed,
the wire mesh of the filter should be visible
from the front.
4
2
1
INSTALLING THE CHARCOAL
FILTER C5
MOUNT THE OVEN (continued) C4
Tu rn t o Select
P ress to En te r
7
5
6 Tighten the outer two screws to the top of the
oven. (While tightening screws, hold the oven
in place against the wall and the top cabinet.)
Insert 3 self-aligning screws
(
1 »
4
Ǝ[ǫ´WKURXJKRXWHU
top cabinet holes. Turn two
full turns on each screw.
Tighten center
screw completely
´[[ǫ´
Install grease filters. See the Owner’s
Manual packed with the oven.
Tu rn to Sele ct
P ress to Enter
Replace the grille and the 2 top screws.
Close the door and replace left side screw.
5
6
3
Front lower tabs
Charcoal filter
Charcoal filter installed
Insert a self-aligning screw through top-center
cabinet hole. Temporarily secure the oven by
turning the screw at least
two full turns after
the threads have engaged . (It will be completely
tightened later.)
3
Cabinet Front
Cabinet Bottom Shelf
Filler Block
Oven Top
Equivalent
to Depth
of Cabinet
Recess
Self-Aligning Screw
This
distance
can NOT
exceed 2”
to ensure
proper
installation
Tu rn to Sele ct
P ress to Enter
Screws
Grille
4
Installation Instructions
