31-7000138 Rev. 0
7
MOUNTING SPACE
NOTES:
• 7KHVSDFHEHWZHHQWKHFDELQHWVPXVWEHƎZLGHDQG
free of obstructions.
• ,IWKHVSDFHEHWZHHQWKHFDELQHWVLVJUHDWHUWKDQƎ
a Filler Panel Kit may be used to fill in the gap between
the oven and the cabinets. Your Owner’s Manual
contains the kit number for your model.
• This oven is for installation over ranges up to
ƎZLGH
• If you are going to vent your oven to the outside, see
Hood Exhaust Section for exhaust duct preparation.
• When installing the oven beneath smooth, flat cabinets,
be careful to follow the instructions on the top cabinet
template for power cord clearance.
• * 13” max: for standard installation, 15” cabinet
depth requires additional steps using an additional
installation kit JX15BUMPWW/BB.
• For models with top venting holes: Do not allow cabinetry
or other objects to block the airflow of the vent.
• PSA9120/PSA9240: The product should not be installed
over any cooktop or range with a combined BTU greater
than 60000 BTU.
ZSA1202: The product should not be installed over any
cooktop or range with a combined BTU greater than
66000 BTU.
Installation Instructions
TOOLS YOU WILL NEED
# 1 and #2 Phillips
screwdriver
Pencil
Ruler or tape
measure and
straight edge
Carpenter square
(optional)
Tin snips (for cutting
damper, if required)
Electric drill with 3 »
16
Ǝ 7 »
16
Ǝ
1 »
2
ƎDQG 5 »
8
ƎGULOOELWV
Hammer (optional) Stud finder or
Filler blocks or scrap
wood pieces, if needed
for top cabinet spacing
(used on recessed
bottom cabinet
installations only)
Gloves
Saw (saber, hole or
keyhole)
Level
Duct and masking tape
Scissors
(to cut template, if
necessary)
Safety goggles
Backsplash
ƎRUPRUH
from the floor
to the top of
the oven
Ǝ
2 Ǝ
Ǝ
min.
16- 1 »
4
Ǝ
Bottom edge of
cabinet needs
WREHƎRU
more from the
cooking surface
ƎPD[
