JennAir Euro-Style Series 30 Inch Double Combination Smart Electric Wall Oven Installation Instructions User Manual
Page 11
11
Cutout Height Is Between 51
3
/
16
" and 52
3
/
16
"
(130 cm and 132.6 cm)
1.
Using 2 or more people, place the oven on its back
on a covered surface.
2.
Install a foot on the left rear spacer using a #8-18 x
3
/
8
" screw.
NOTE:
Position the foot so the short side of the foot is facing
toward the top of the oven.
3.
In the same manner, install a foot on the right rear of the oven.
4.
Install a front foot on the left front using a #8-18 x
3
/
8
" screw.
NOTE:
Position the foot so the long side of the foot is facing
toward the top of the oven.
5.
In the same manner, install a font foot on the right front
of the oven.
6.
Using 2 or more people, place the oven in its upright position.
7.
Go to the “Make Electrical Connection” section.
C
B
A
A. Spacer
B. Foot
C. #8-18 x
3
/
8
" screw
A
B
C
A. Front foot
B. #8-18 x
3
/
8
" screw
C. Spacer
