JennAir Euro-Style Series 30 Inch Double Combination Smart Electric Wall Oven Installation Instructions User Manual
Page 8
8
Cutout Height Is Between 26
15
/
16
" and 27
11
/
16
"
(68.4 cm and 70.3 cm)
1.
Using 2 or more people, place the oven on its back
on a covered surface.
2.
Remove the foot from the right front spacer by removing
the #8-18 x
3
/
8
" screw.
NOTE:
Do not remove the spacer.
3.
In the same manner, remove the feet on the right rear,
left front, and left rear of the oven.
4.
Using 2 or more people, place the oven in its upright position.
5.
Go to the “Make Electrical Connection” section.
Cutout Height Is Between 28
11
/
16
" and 29
7
/
16
"
(72.8 cm and 74.8 cm)
1.
Using 2 or more people, place the oven on its back
on a covered surface.
2.
Remove the foot from the right front spacer by removing
the #8-18 x
3
/
8
" screw.
NOTE:
Do not remove the spacer.
3.
Rotate the foot 90°, so the short side of the foot
is positioned toward the top of the oven.
A
B
C
A. Spacer
B. Foot
C. #8-18 x
3
/
8
" screw
A
B
C
A. Spacer
B. Foot
C. #8-18 x
3
/
8
" screw
