2
BUILT-IN OVEN SAFETY
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting
installation. Read and follow the instructions provided
with any tools listed here.
Tools Needed
■
Phillips screwdriver
■
Measuring tape
■
Hand or electric drill (for wall cabinet installations)
■
1" (2.5 cm) drill bit (for wall cabinet installations)
■
Level
■
Flat-blade screwdriver
Parts Needed
■
UL listed or CSA approved conduit connector
■
UL listed wire connectors
■
Warming Drawer Deflector Kit (for ovens installed
above a warming drawer)
Order Part Number W10531010 for black 30" (76.2 cm) kit
Order Part Number W10536339 for stainless steel
30" (76.2 cm) kit
To order, see the “Assistance or Service” section
of the Use and Care Guide.
■
Flush Installation Kit (for Single and Double installed at flush
installation)
Order Part Number W10837578 for black 30" (76.2 cm) kit
Order Part Number W10837579 for stainless steel
30" (76.2 cm) kit
To order, see the “Assistance or Service” section
of the Use and Care Guide.
Parts Supplied
■
#8-14 x 1" screws - single ovens (2), double ovens (4)
■
#8-18 x 3 /
8
" screws - bottom vent (2)
■
#8-18 x 1 /
4
" screws - bottom vent trim (4)
■
#8-18 x 3 /
8
" screws - double oven feet (4)
■
Bottom vent
■
Bottom vent trim
■
Rear feet - double oven (2)
■
Front feet - double oven (2)
Check local codes. Check existing electrical supply.
See “Electrical Requirements.”
It is recommended that all electrical connections
be made by a licensed, qualified electrical installer.
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
■
Cabinet opening dimensions that are shown must be used.
Given dimensions provide minimum clearance with oven.
■
Recessed installation area must provide complete
enclosure around the recessed portion of the oven.
■
Grounded electrical supply is required. See
“Electrical Requirements” section.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
