M (E2) 10/2014 page 33/71
Program entry as set-point ramp (example)
On
Off t/min.
Operation line 1 = air flap
W/°C
t/min.
01 02 03 04
0
50
100
150
200
250
30 120 180 380
05
Tolerance
minimum
Tolerance
maximum
Program table corresponding to the diagram above:
Program
section
Set-point
temp.
Fan Section
time
Operation
line1
Target
section
No. of
cycles
Min.
tolerance
Max.
tolerance
01 50 100 % 00:30:00 Off 1 0 -1999 +9999
02 100 100 % 01:30:00 Off 1 0 -5 +5
03 200 100 % 01:00:00 Off 1 0 -2 +2
04 200 100 % 03:20:00 Off 1 0 -1999 +9999
05 100 100 % 00:00:01 Off 1 0 -1999 +9999
Now enter the values of the above program table into one of the 25 program places of the controller MB1:
PGM
08:43:55 15.02.02
PGM
08:43:55 15.12.13
