15.3 M technical data
Unit size 53 115 240 400 720
Exterior dimensions
Width
mm
inch
635
25.00
835
32.87
1035
40.75
1235
48.62
1235
48.62
Height (incl. feet/castors)
mm
inch
780
30.71
865
34.06
985
38.78
1185
46.65
1695
66.73
Depth
mm
inch
575
22.64
645
25.39
745
29.33
765
30.12
865
34.06
Depth plus door handle, instrument
panel, and exhaust duct
mm
inch
105
4.13
105
4.13
105
4.13
105
4.13
105
4.13
Wall clearance rear
mm
inch
100
3.94
100
3.94
100
3.94
100
3.94
100
3.94
Wall clearance side
mm
inch
160
6.30
160
6.30
160
6.30
160
6.30
160
6.30
Exhaust duct, outer diameter
mm
inch
52
2.05
52
2.05
52
2.05
52
2.05
52
2.05
Steam space volume
l
cu.ft.
77
2.72
158
5.58
308
10.88
498
17.60
869
30.71
Number of door(s) 1 1 2 2 2
Interior dimensions
Width
mm
inch
400
15.75
600
23.62
800
31.50
1000
39.37
1000
39.37
Height
mm
inch
400
15.75
480
18.90
600
23.62
800
31.50
1200
47.24
Depth
mm
inch
340
13.39
410
16.14
510
20.08
510
20.08
610
24.02
Interior volume
l
cu.ft.
53
1.9
115
4.1
240
8.6
400
14.3
720
25.7
Number of racks, stainless steel, regular / max. 2/5 2/6 2/7 2/10 2/16
Load per rack
Kg
lbs
15
33
20
44
30
66
35
77
45
99
Permitted total load
Kg
lbs
40
88
50
110
70
155
90
199
120
265
Weight (empty)
Kg
lbs
61
135
89
196
131
289
173
382
203
448
Temperature data
Temperature range, 5 °C above ambi-
ent up to
°C
°F
300
572
300
572
300
572
300
572
300
572
Temperature fluctuation ≤ ± K 0.3 0.3 0.3 0.3 0.3
Temperature uniformity
(variation) 1)
at 70 °C ± K 0.5 0.6 0.8 0.7 0.7
at 150 °C ± K 1.3 1.5 1.5 1.5 1.9
at 300 °C ± K 2.8 2.8 2.8 5 4.6
Heating up time 2)
to 70 °C min 5 5 6 6 7
to 150 °C min 15 16 19 18 21
to 250 °C min 35 36 42 44 51
