User Manual
25
 Area: Click the [Setup] button to enter into area setup interface shown as Picture 5-37.
 Sensitivity: allow you to set sensitivity level of motion detection from higher to low with 8 being the most
sensitive.
 Alarm out: allow you connect external alarm sensor.
 Latch time: you can set how long the alarm devices will sound when object move is detected (10s, 20,
40s, 60s);
 Show Message: You can set show message on the screen when motion alarm is detected.
 Buzzer time: you can set how long the buzzer will sound when motion is detected (10s, 20, 40s, 60s);
 Send Email：Allows you set the alarm images is issued to a specified email.
 Full screen:
The function is defaulted to “On". When the motion is detected, the corresponding channel
will be switched to the full screen mode.
 Record Channel: the record channel will be activated when the object move is detected.
 Post Recording: you can set how long alarm record will last when alarm ends (30s, 1minute，2minute，
5minute).
5.3.5.2 Alarm Set
Click [Main MenuAlarmAlarm] to enter into the below window shown as Picture 5-38. Now you can
perform alarm set based on different status.
 Alarm In: allow you select one desired channel
 Alarm Type: allows you select the three options
– NO (Normal Open), NC (Normal Close) and Disable.
Set to “Normal Open”, I/O status Alarm will be activated while sensor is ON; set to “Normal Close”, I/O
status alarm will be activated while sensor is OFF; set to “OFF”, I/O status alarm will not be triggered.
 Alarm out: allow you connect external alarm sensor.
 Latch time: you can set how long the alarm devices will sound when external sensor alarm is detected
(10s, 20, 40s, 60s);
 Show Message: You can set show message on the screen when sensor alarm is detected.
 Buzzer time: you can set how long the buzzer will sound when sensor alarm is detected (Off, 10s, 20, 40s,
 Copy: allow you copy current channel parameters to any
other channel or all channels.
The channel will be separated into a 36x44grids (PAL
mode) or 30x44grids (NTSC mode). When any object moves
into the motion detection area, and the area where the object is
located is displayed in red and motion detection will be
triggered. In the semi-transparent area the motion detection is
not activated.
Picture 5-37
Picture 5-36 8CH 4CH
