Basic Operation 2-5
3. Multiple Controller with Multiple Broadcast Groups:
In a Multiple Controller with Multiple Broadcast (Split Court Operation)
system, there are additional All Sport Controllers that can control multiple
scoreboards. The broadcast group jumper is used to select broadcast group
1, 2, 3, or 4. By changing All Sport settings to a Broadcast address, a single
All Sport Controller can control all scoreboards or specific groups of
scoreboards (defined by the broadcast group). One example of this scenario
is split court operation in Basketball installations, where scoreboards are
used to score multiple games at once, but can be grouped together to show
one game if necessary. Refer to the drawings listed on the previous page
for more information.
The All Sport Console will automatically detect when a radio transmitter is installed
and will prompt the user for transmitter settings.
The All Sport Console will show the current transmitter radio status on the LCD
when a code is entered. The table on the next page describes the broadcast groups
and channel settings.
LCD Display Action
The LCD will toggle
these screens
RADIO SETTINGS
BCAST Y CHAN XX
The LCD shows the current radio settings along with a
prompt to accept or modify these values.
If the radio settings are correct, press <ENTER>
If these values are incorrect, press <CLEAR>
If <CLEAR> is pressed to modify the radio settings, the
LCD at the left is shown, allowing edit of the Channel or
Broadcast group setting.
(Continued on next page)\
(Continued from previous page)
LCD Display Action
