Note: The SCS-R and Sentinel 32 models offer two independent network
interface ports. Only the first port (NETWORK 1) is enabled by default.
2 . 3 . 3 AC P ow e r
2.3.3.1 SCS80 / SCS160 / SCS320 / SCS480
A single IEC-type Power Entry Module is located on the rear of the chassis. The power
entry module incorporates a replaceable protective fuse (2A) and an On/Off switch. An
IEC cord set is provided with each SCS chassis. Connect the cord set to a local AC
power source. Turn the power switch on.
2.3.3.2 SCS80R / SCS160R / SCS320R / Sentinel 32
Two removable AC Power Modules, identified as Left and Right are found on the rear
of the chassis. Either AC module can fully support the system and, with both turned
on, operate redundantly. The SCS-R and Sentinel 32 systems have an AC power
monitoring capability to alert the system administrator in the event of an AC power
outage.
Each AC Module has an IEC-type power entry module. The power entry module features a
replaceable, protective fuse (2A) and an On/Off switch. Two IEC cord-sets are provided
with each SCS-R and Sentinel 32 chassis. Connect both cord sets to a standard AC
power source. Turn both power switches ON ( l ).
Warning! Turn the module POWER OFF and remove its power cord BEFORE
removing a power module. A hazardous voltage condition might otherwise exist.
2.3.3.3 SCS480R
Two removable AC Power Modules, identified as Left and Right are found on the front of
the chassis. Either AC module can fully support the system and if both are turned on,
will operate redundantly. The SCS-R and Sentinel 32 systems have an AC power
monitoring capability to alert the system administrator in the event of an AC power
outage. A 250VAC 2A fuse is provided on each SCS480R Power Module and can be
replaced when the module is removed from the unit.
2.3.4 DC Power
The Sentinel and SCS-Rs can be equipped with optional removable -48 VDC Power
Modules in place of the AC Power Modules described in paragraph 2.3.3. Either
module will fully power the system and will operate redundantly if power is applied to
both. The power monitoring circuitry of the SCS-R and Sentinel alert the system
administrator in the event of power loss to either module.
2.4 User Access Control
Access to a Port is controlled on a per-user basis via a user profile which is stored as a file
on the local SCS. This profile is created by the root user using the command ‘adduser’. See
Section 8.1.1, adduser, on page 51. NIS support is also available.
