Restoring the Settings (Restore)
37
Restoring the Settings (Restore)
You can use the backup data that you created on your computer to restore the settings of the JX-08.
1.
Connect your computer to the JX-08 with a USB cable.
2.
While holding down the [MENU] button, turn on the power.
The JX-08 operates in USB mass storage mode. The JX-08 is recognized by your computer as an external storage device. It
takes around 20 seconds for the connection to be recognized.
3.
Open the “JX-08” on your computer.
The “BACKUP” folder is shown in the JX-08.
4.
Delete the “BACKUP” folder.
5.
Copy (drag and drop) the backup file that you backed up on your computer to the “RESTORE” folder on the JX-
08.
6.
Disconnect the JX-08 from your computer.
If you’re using Windows, click the Safely Remove Hardware icon in the taskbar (
) and then click “Eject Boutique.”
If you’re using macOS, drag the JX-08 icon to the trash.
7.
Press the [PAGE/TIE] button on the JX-08.
The restore operation begins, and the [PAGE/TIE] button blinks. “
donE
” is displayed once the restore operation is finished.
8.
Turn off the JX-08.
