Configuring the Settings of This Unit
39
Step
buttons
Parameter (as
displayed)
Value
Explanation
[9]
N.UEL
0
–
3
Adjusts how much the effect changes the MIXER envelope according to
how hard you press the keys (velocity).
[10]
bEnd
2
,
3
,
4
,
7
(semitones)
Sets the variable pitch range for the pitch bend.
[11]
N.Lfo
-63
–
63
Adjusts the depth of the modulation effect.
[12]
P.crU
This sets the curve used by the portamento effect to change the pitch.
orG
The same curve of change used on the original model is applied.
LinE
A linear curve of change is applied.
E.1
A non-linear curve (gradual slope) of change is applied.
E.2
A non-linear curve (steep slope) of change is applied.
[13]
AF.LF
-63
–
63
Adjusts how much the LFO is changed by aftertouch (only enabled
when a product featuring aftertouch is connected).
[14]
AF.Fq
-63
–
63
Adjusts how much the low-pass filter (LPF) is changed by aftertouch
(only enabled when a product featuring aftertouch is connected).
[15]
AF.LU
-63
–
63
Adjusts how much the tone is changed by aftertouch (only enabled
when a product featuring aftertouch is connected).
You can also press a corresponding step button to select the parameter items.
