Effect Parameters

54

You can also press a step button to select the parameter items.

Script 90

You can also press a step button to select the parameter items.

M StagePhsr

Step

buttons

Parameter

Value

Explanation

[1]

tyPe

PhA2

This creates extremely large phase differences for a deep

phaser effect.

[2]

Off

,

On

Turns the effects on/off.

[3]

NodE

4

,

8

,

12

,

16

,

20

,

24

(STAGE)

Number of stages in the phaser

[4]

Nanu

0

127

Center frequency from which the sound is modulated

[5]

Sync

OFF

,

ON

When this is ON, the effect synchronizes with the tempo of

the rhythm.

8.2.1. Tempo Settings

(P.28)”

[6]

tiNE

0.05

10.00

(Hz)

Frequency of modulation

[7]

notE

12.1.18. About note

values

(P.57)”

[8]

dEPt

0

127

Depth of modulation

[9]

rESo

0

127

Amount of feedback

[10]

NiX

0

127

Volume of phased sound

[11]

PAn

L

64

r

63

Stereo position of the output sound

[12]

Lo

-15

15

(dB)

Amount of low range boost/cut

[13]

Hi

-15

15

(dB)

Amount of high range boost/cut

[14]

LEU

0

127

Output level

You can also press a step button to select the parameter items.

SuperFilter
