User Manual – Rev AY AMETEK Programmable Power
MX Series 117
WAVE GROUP [3Pi Controller only] Sets the user defined waveform group that
will be loaded at power on. Available groups are 0, 1, 2 and 3.
Each group can contain up to 50 user-defined waveforms. A
waveform group can only be loaded at power up. To change
groups, you must change this field to the desired new group and
cycle the power to the AC source or issue a *RST command
over one bus.
CLOCK MODE Sets the clock source used at power up. Available settings are
Stand Alone (STAND), MASTER (-LKM clock and lock master),
and AUX (-LKS clock and lock auxiliary).
NO. OUTPUT [MX30-3Pi or MX45-3Pi model only] Sets the phase mode at
power up. Available options are single-phase mode (ONE),
three-phase mode (THREE) or last used phase mode (LAST). If
the phase mode option is not installed, this field is fixed to ONE
or THREE.
VOLT ALC Determines ALC mode at power on. The ALC mode adjusts the
output voltage based on internal voltage measurement system
and provides enhanced output regulation and accuracy.
Available settings are ON, OFF or REG (Series II only).
