External Accessories (External to MX chassis)
7003-416-1 Input / Output wiring junction box. Connects two to six three-phase MX45
cabinet outputs, neutral and ground to a common output terminal block
housed in a metal enclosure junction box. Can also be used to connect
multiple MX chassis to common AC input service. See section 3.13 for
details.
7003-424-1 Output noise filter, 3 phase + neutral. May be used to reduce output
noise of MX30 or MX45 when testing EUT’s for conducted emissions.
This is an external filter that attenuates the 250 KHz ripple frequency on
the MX output by > 20 dB. The filter is rated for 125A per phase and 800
Hz. For multi-box configurations, one filter is required per chassis.
Connects to MX30 or MX45 three-phase output terminal only.
7003-426-1 Output fuse box. Provides added protection for MX system
configurations consisting of more than 2 MX cabinets. (MX135, MX180,
MX225 and MX270).
2.6.1 -HV Option Specifications
The -HV option provides an AC only output range of 0 to 400 Vac L-N. Specifications unique to the -
HV option are shown in the table below.
Output Parameter MX30 MX45 MX60 MX90 MX135
Modes
Pi Controller AC
Voltage:
Ranges (L-N): 0 -400 V
Resolution: 0.1 V
Accuracy: ± 0.25% of Full Scale / ± 1.0 Vac rms
Output Coupling AC coupled
Power (total power for all phases, either range, at full scale voltage)
AC Mode 30 KVA 45 KVA 60 KVA 90 KVA 135 KVA
Current
Note: Current, maximum amps per phase available between 50 and 100 % of voltage range.
MX30-1
76.5 A
MX30-3, per
phase
25.5 A
MX45-1
112.5 A
MX45-3, per
phase
37.5 A MX60-3, per
phase
50 A MX90-3, per
phase
75 A MX135-3,
per phase
112.5 A
Peak Current
AC Mode MX30-1
337.5 A
MX30-3, per
phase
112.5 A
MX45-1
337.5 A
MX45-3, per
phase
112.5 A MX60-3, per
phase
225 A MX90-3, per
phase
225 A MX135-3,
per phase
337.5 A
Frequency:
Range: 45 Hz – 819 Hz
with –LF option: 45 Hz – 500 Hz
