User Manual – Rev AY AMETEK Programmable Power
MX Series 121
NOTE: Options –A350, AMD24 and –B787 are only visible using the *OPT? Bus command and do
not have a visible field in the configuration screen for firmware revisions lower than 4.60.
For FW revision of 4.60 or higher, see CONFIGURATION SETUP 4 screen.
CONFIGURATION SETUP 4
(Series II models with FW 4.60 or higher only)
Note that the fourth configuration screen is only available on MX models with firmware revision
4.60 or higher. For units with older models, refer to the CONFIGURATION SETUP 3 screen.
MB This entry was moved from CONFIGURATION SETUP 3 to
CONFIGURATION SETUP 4. Its purpose remains the same.
For details, see CONFIGURATION SETUP 3 manual section on
previous page.
MANUAL This field does not apply to MX products and is always set to
N/A.
OPT0, OPT1, OPT2 This field indicates the presence of the following three options:
OPT0 = A350 Avionics option (-A350)
OPT1 = AMD24 Avionics option (-AMD)
OPT2 = B787 Avionics option (-B787)
The scroll through the three available OPTn fields, use the
shuttle. ON indicates the option is present, N/A indicates the
option is not installed.
LAN This field indicates the presence of the LAN Ethernet interface
option. ON indicates the option is present, N/A indicates the
option is not installed.
SNK This field indicates the presence of the Current Sink
regenerative mode option. ON indicates the option is present,
N/A indicates the option is not installed.
FC This field, when ON, indicate the presence of the frequency
control option. This option will cause the frequency to fluctuate
±0.25% of the program value.
