AMETEK MX Series Rev: AY User Manual
Page 193
User Manual - Rev AV
AMETEK Programmable Power
MX Series
193
Ref.
CI P/N
Description
Vendor
Qty
Location
EECLS57.22NTW
K5
245237
Relay, 3C, 100A, 24VDC
EE Controls
EECLS57.22NTW
1
K4
245237
Relay, 3C, 100A, 24VDC
EE Controls
EECLS57.22NTW
1
Ref.
CI P/N
Description
Vendor
Qty
Location
Amplifier Assy. 15kVA 7003-418-1
A1
7003-704-1
PC Assy., Modulator
AMETEK PP
1
A7, A8, A9
Q1
330436
Transistor, IGBT
IXYS, IXGX60N60C2D1
4
A7, A8, A9
Q2
330436
Transistor, IGBT
IXYS, IXGX60N60C2D1
4
A7, A8, A9
Q3
330436
Transistor, IGBT
IXYS, IXGX60N60C2D1
4
A7, A8, A9
Q4
330436
Transistor, IGBT
IXYS, IXGX60N60C2D1
4
A7, A8, A9
Amplifier Assy. 15kVA 7003-425-1 / 7003-425-2
A1
7003-720-1
PC Assy., Modulator (-1)
AMETEK PP
1
A7, A8, A9
A1
7003-724-1
PC Assy., Modulator (-2)
AMETEK PP
1
A7, A8, A9
Q1
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
Q2
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
Q3
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
Q4
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
Amplifier Assy. 15kVA - 7003-418-1 / 7003-425-1 / 7003-425-2
A3
7003-405-1
Heat sink Assy. Amplifier
AMETEK PP
1
A7, A8, A9
A4
7003-405-1
Heat sink Assy. Amplifier
AMETEK PP
1
A7, A8, A9
A5
7003-707-1
PC Assy., Output Filter
AMETEK PP
1
A7, A8, A9
A6
7003-707-2
PC Assy., Output Filter
AMETEK PP
1
A7, A8, A9
A7
7003-716-1
PC Assy., PFC
AMETEK PP
1
A7, A8, A9
A8
7003-708-1
PC Assy., Fan Control
AMETEK PP
1
A7, A8, A9
A8
7003-717-1
PC Assy., Snubber. (-1)
AMETEK PP
1
A7, A8, A9
A8
7003-725-1
PC Assy., Snubber. (-2)
AMETEK PP
1
A7, A8, A9
B1
241183
FAN, 6"
ROTRON JQ24B2
1
A7, A8, A9
B2
241183
FAN, 6"
ROTRON JQ24B2
1
A7, A8, A9
Amplifier Assy. 15kVA 7003-433-2 / 7003-433-5
A1
7003-727-1
PC Assy., Modulator (-1)
AMETEK PP
1
A7, A8, A9
7003-727-5
PC Assy., Modulator (-5) –SNK
AMETEK PP
1
A7, A8, A9
A5
7003-726-1
PC Assy., Output Filter
AMETEK PP
1
A7, A8, A9
A6
7003-726-2
PC Assy., Output Filter
AMETEK PP
1
A7, A8, A9
Q1
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
Q2
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
Q3
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
Q4
330450
Transistor, FET
INFINEON, IPW60R045CPXK
4
A7, A8, A9
CR13
310387
Diode, FRcy, 30A, 1000V
APT, APT30D100B
1
CR14
310387
Diode, FRcy, 30A, 1000V
APT, APT30D100B
1
CR15
310387
Diode, FRcy, 30A, 1000V
APT, APT30D100B
1
CR16
310387
Diode, FRcy, 30A, 1000V
APT, APT30D100B
1
Q1
330437
Transistor, IGBT
FUJI, 2MBI150NC-060
1
A7-PFC
Q2
330437
Transistor, IGBT
FUJI, 2MBI150NC-060
1
A8-PFC
Q3
330437
Transistor, IGBT
FUJI, 2MBI150NC-060
1
A9-PFC
Table 8-1: Replaceable Parts
