Page 17
4.2.5.1 Soft Knee Compression
SOFT: Rounded response curve
•
Gradual onset of compression (fade-in up to the set ratio)
•
Similar to an “over-easy” type knee
•
More transparent
4.2.5.2 Hard
Knee
Compression
HARD: Sharp response curve
•
Immediate onset of compression (sudden transition to set ratio)
•
More aggressive and noticeable
4.2.6 THRUST®
The 527 Compressor includes API’s patented THRUST® circuit that can be switched in or out as
needed. This places the THRUST® filter before the RMS detector that decreases the compressor’s
reaction to low frequency content. The result is a noticeable increase of punch and low
frequencies, but a uniformly compressed signal. It’s the “little more punch” switch!
The THRUST® circuit can be engaged using the THRUST® switch.
THRUST®: Inserts the THRUST® filter before the RMS detector
•
Illuminates when engaged
16
