CRS-500 1:N Redundancy System Revision 2
CSU Front Panel Operation MN-CRS500
7–20
7.2.2.4 SELECT: UTILITY
UTIL: Clock Display
Name Firmware NTP
Use the ◄ ► arrow keys to select utility functions Clock, Display, Name, Firmware, or NTP, and
then press ENTER.
7.2.2.4.1 UTIL: Clock (Set Real-Time Clock)
Edit time and date:
12:00:00 24/04/12 (ENT)
To edit the time and date settings of the real-time clock: Use the ◄ ► arrow keys to select the
digit to be edited, and then use the ▲▼ arrow keys to change that digit. Press ENTER when
done.
In accordance with European convention, the date is displayed in DAY/MONTH/YEAR
(dd/mm/yy) format. The time is displayed per Coordinated Universal Time standard
(UTC+0) in HOURS/MINUTES/SECONDS (hh:mm:ss) format.
7.2.2.4.2 UTIL: Name (Unit Name)
Edit Unit Name:
---- SWITCH 11 ----
To edit the switch Unit Name string: On the bottom line, use the ◄ ► arrow keys to first select
the cursor position, and then use the ▲▼ arrow keys to edit that alphanumeric character. Press
ENTER when done.
Only the first 24 characters on the bottom line are available.
The following characters are available: [space] ( ) * + - , . / 0-9 and A-Z.
7.2.2.4.3 UTIL: Firmware
Firmware: Info Select
To display the firmware information or allow selection of Bulk firmware: Use the ◄ ► arrow
keys to select Info or Select, and then press ENTER.
