4.3.2.3.2 Ethernet System Communication Cable Connections –
Unbalanced G.703 Traffic Data
Referring to Figure 4-9:
• First, for the Redundant Modem, connect the PP/CAT5FF7FTGY cable between the
Redundant Modem and the CSU rear panel CRS-512 Ethernet Interface as follows:
o
Redundant Modem RJ-45 port labeled “J4 |MGMT to
o
Any unused RJ-45 port (i.e., “Port 1” through “Port 12” on the CSU rear panel
CRS-512 Ethernet Interface.
• Then, for each Traffic modem, connect a PP/CAT5FF7FTGY cable between the CSU
CRS-512 Ethernet Interface and an installed Traffic Modem as follows:
o
Any unused RJ-45 port (i.e., “Port 1” through “Port 12” on the CSU rear panel
CRS-512 Ethernet Interface to
o
Traffic Modem RJ-45 port labeled “J4 |MGMT”.
