4. The table below lists available paging speakers that can be used as a “dummy speaker” pick-up
device and the initial gain settings. Usable audio frequency response is also listed. It may be
necessary to further adjust the gain to match noise sensitivity.
Table 8. Initial Gain Settings
Manufacturer Speaker
Model
Gain Usable
AFR
GAI-Tronics 13350
60
dB Wide
DNH
HP15-8
45 dB
Less than 2.5 kHz
DNH B406-8-W
60
dB
Wide
DNH B650-8
60
dB
Wide
GAI-Tronics
13314-002 (driver)
45 dB
Less than 2.5 kHz
GAI-Tronics
13310-101 (driver)
45 dB
Less than 2.5 kHz
ALC Remote Module Specifications
Phantom power input ........................................ (phantom from master) 20 to 30 V dc @ 35 mA maximum
Physical size .................................................................................................. 4.0 W
4.0 L ~2.0 D inches
Operating environment ............................................... −40º C to 80
C @ 95% humidity (non-condensing)
Remote input .............................................................................. Dedicated 8-ohm speaker or dynamic mic,
Input is transformer-isolated and protected against directly-applied signals up to 120 V ac
