Specifications
General
Temperature range .................................................................................................................. 0º C to +50º C
Humidity ................................................................................................................................... 95% at 50º C
Physical size................................................................................................ 9.5 H
× 14.5 W × 13.5 D inches
Power input ............................................................. 120/240 V ac, 15% (47 to 63 Hz); or +10.5 to 18 V dc
Weight (without options) ................................................................................................................................
ICP9004A ................................................................................................................................... 18.0 lbs.
ICP9008A ................................................................................................................................... 19.5 lbs.
ICP9012A ................................................................................................................................... 21.0 lbs.
Audio General
Audio response ....................................................................................................... +3 dB at 300 to 3000 Hz
Hum and noise ............................................................. Transmit – Less than 50 dB below full rated power
Receive – Less than 55 dB below full rated power
Audio distortion .............................................................................................................. Less than 2% THD
Compression ............................................................................... Input variations of 30 dB output variation
Receiver Audio
Input .............................................................................................. −25 dBm to +11 dBm adjustable
Crosstalk ............................................................... 60 dB below rated output levels at rated line impedance
Input impedance............................................................................................................... 600 ohms nominal
Tone Remote Control
Guard tone............................................................................... 2100, 2175, 2325, 2800 (default = 2175 Hz)
Function tones............................................................................................................ F1 Transmit: 1950 Hz
F2 Transmit: 1850 Hz
F3 Transmit: 1350 Hz
F4 Transmit: 1250 Hz
Monitor: 2050 Hz
Function tones are selectable via GAI-Tronics’ CARD Suite Software Application
Transmit Audio
Condenser microphone ......................................................................... Selectable, digital steps 1 through 5
Microphone sensitivity ......................................... Reference 165 mV, selectable, digital steps 1 through 5
Audio out to phone line ................................................................ −20 dBm to +11 dBm into 600-ohm load
Line balance....................................................................................................................... 70 dB at 1000 Hz
DC Remote Control
Audio out to phone line ............................................................................................ F1 Transmit: +5.5 mA
F2 Transmit: +12.5 mA
Monitor: −2.5 mA
Output currents are selectable via GAI-Tronics’ CARD Suite Software Application
