Installation CommandPLUS Series Desktop Console Installation and Service Manual
12/10 14
Types of Base Station Control
The CommandPLUS Console is capable of either tone or dc control depending on the position of jumpers
JU620 through JU623. For dc control, the console must have option CP0010 or XCP0010. Refer to
Table 2.
Table 2. Jumper Positions for DC or Tone Control Selection
Function Jumper No. Position
Ch. 1, 5, 9 JU620 IN
OUT Tone Control
DC Control (option CP0010 or XCP0010)
Ch. 2, 6, 9 JU621 IN
OUT Tone Control
DC Control (option CP0010 or XCP0010)
Ch. 3, 7, 11 JU622 IN
OUT Tone Control
DC Control (option CP0010 or XCP0010)
Ch. 4, 8, 12 JU623 IN
OUT Tone Control
DC Control (option CP0010 or XCP0010)
N OTE : If operating in dc mode, the console must also be programmed for dc under Type of Interface in
the CARD Software.
Two Wire Control (default)
In this configuration, a single two-wire line is used to carry the control tones or dc control currents (as
applicable per channel) and the transmitter audio, from the CommandPLUS Series Console to the base
station. This same 2-wire line is used to return the receive audio back to the console from the base
station. Refer to Table 3 for the appropriate system configuration.
Four Wire Audio/Control
In this configuration, one pair of lines is used to carry both control tones or dc control currents (as
applicable per channel) and the transmitter audio from the CommandPLUS Series Console to the base
station. The other pair is used to carry the receive audio from the base station back to the console. Refer
to Table 3 for the appropriate system configuration.
N
OTE : In this configuration, RX audio can still be received on original 2-wire pair.
Table 3. Slave Module – 2-Wire/4-Wire
Function Jumper No. Position
Ch. 1, 5, 9 – 2W/4W Select JU602 2W – 2 wire control
4W – 4 wire control
Ch. 2, 6, 9 – 2W/4W Select JU606 2W – 2 wire control
4W – 4 wire control
Ch. 3, 7, 11 – 2W/4W Select JU610 2W – 2 wire control
4W – 4 wire control
Ch. 4, 8, 12 – 2W/4W Select JU614 2W – 2 wire control
4W – 4 wire control
