eZ-TOMAS & eZ-TOMAS Remote 988490 Monitoring a Machine 2-7
EZ-TOMAS 5.5.09
ASCII Time Waveform Data Report generated 30-Aug-2006 11:15:01
Project Path: J:\Tomas Software\Data\Unit #2 Pre Outage\Ops Duwn 92603
Start Date: 26-Sep-2003 22:39:13
End Date: 26-Sep-2003 22:43:00
Sampling Rate: 1280. samples/second
Delta Time: 0.00078125 seconds
1. Brg 1Y mils
2. Brg 1X mils
4. Brg 2 "X" mils
Date / Time mSec Sample Time Waveform Data
26-Sep-2003 22:39:13 190 1 0.1830 -1.014 1.362
26-Sep-2003 22:39:13 190 2 0.6764 -1.136 1.266
26-Sep-2003 22:39:13 190 3 1.131 -1.195 1.460
26-Sep-2003 22:39:13 190 4 1.456 -1.136 1.793
26-Sep-2003 22:39:13 190 5 1.702 -0.9803 1.991
26-Sep-2003 22:39:13 190 6 1.773 -0.8245 1.996
26-Sep-2003 22:39:13 190 7 1.729 -0.6158 1.920
26-Sep-2003 22:39:13 190 8 1.580 -0.3180 1.988
26-Sep-2003 22:39:13 190 9 1.288 -0.1010 1.878
26-Sep-2003 22:39:13 190 10 0.8858 0.1411 1.709
Etc…
Erase History Data
Use the Erase History Data option with caution. This
menu item will erase History Data for the project. All
data for the active project will be permanently removed.
It is not recoverable.
Warning for Erase History
Erase Alarm Log
Use the Erase Alarm Log option with caution. This
menu item will erase the Alarm Log file for the project.
It is not recoverable.
Warning for Erase Alarm Log
Print “Print” brings up the Print Window for printing the current screen.
Exit Closes the eZ-TOMAS application.
