TASCAM MD-CD1MKIII
53
17 – Specifications
MD deck
Type
MiniDisc recorder
Discs
MiniDisc format
Number of channels
2 channels (stereo)/1 channel (mono)
Rec modes
Stereo/Mono/LP2/LP4
Recording format
Magnetic field modulation overwrite
Recording time
Standard
(stereo)
Mono LP2 LP4
60-minute disc 60 120 120 240
74-minute disc 74 148 148 296
80-minute disc 80 160 160 320
Sampling frequency
44.1 kHz
Compression system
ATRAC (Adaptive Transform Acoustic Coding)
CD deck
Type
Compact Disc player
Discs
CD-DA (12 cm/8 cm), CD-ROM (12 cm/8 cm), CD/CD-R/
CD-RW
File system
ISO9660 LEVEL 1/2/ROMEO/JOLIET format
Formats
Audio CD (CD-DA), MPEG Audio Layer III (MP3), WAV
Audio CD playback specifications
Sampling frequency: 44.1 kHz
Quantization bit rate: 16 bit
Number of channels: 2
MP3 playback specifications
Audio modes: STEREO, JOINT STEREO, DUAL
CHANNEL, MONO
Sampling frequency: 44.1 kHz
Bit rate:
32 kbps - 320 kbps, or VBR
WAV playback specifications
Sampling frequency: 44.1 kHz
Quantization bit rate: 16 bit
Input ratings (MD inputs)
Analog inputs (Unbalanced)
Connector: RCA pin jack
Input impedance: 22 kΩ
Nominal input level: –10 dBV (0.32 Vrms)
Maximum input level: +6 dBV (2.0 Vrms)
Minimum input level: –22 dBV (0.08 Vrms)
Digital inputs (Coaxial)
Connector: RCA pin jack
Format: IEC-60958-3 (S/PDIF, conforming
to SCMS)
Sampling frequency
range
32 kHz - 48 kHz
Digigal inputs (Optical)
Connector: TOS (JEITA RC-5720C)
Format: IEC-60958-3 (S/PDIF, conforming
to SCMS)
Output ratings
Analog outputs (Unbalanced)
Connector: RCA pin jack
Output impedance: 200Ω
Nominal output level: –10 dBV (0.32 Vrms)
Maximum output level: +6 dBV (2.0 Vrms)
Headphone outputs
Connector: 6.3 mm stereo standard jack.
Maximum output: 20 mW + 20 mW (1 kHz, 0.1%, 32Ω)
Digital outputs (Coaxial)
Connector: RCA pin jack
Compatible signal format: IEC-60958-3 (S/PDIF,
conforming to SCMS)
Digital outputs (Optical)
Connector: TOS (JEITA RC-5720C)
Format: IEC-60958-3 (S/PDIF, conforming
to SCMS)
