6618-3202 48
<”data”1>
The interpretation of this field depends on the service specified for the entry.
The field accepts 0 – 20 characters.
Service Function of <”data1”>
DIAL Number to connect to
SMS Phone number of SMS receiver
TEXT Phone number of TEXT receiver, if left empty the TEXT
is sent out on the local DTE connection.
EMAIL Reserved.
OUT Phone number of the modem where the output shall be
set. If <data1>, is empty the transfer will be to the local
digital output.
CMD AT command string to be executed when the entry is
trigged, can be used to modify the trigger condition
TRANS Phone number of the modem to which the transparent
I/O should occur. For dependencies of other parameters
and line type, Please See Table 1
<data1> Makes a connection to the number
defined and start
= number Transparent I/O transfer between
the two units.
<data1> = empty Transparent I/O transfer will use an
existing data connection.
<”data2”>
Interpretation of field <”data2”> is also service dependent the size is 0 – 160 characters.
Service Parameter <”data2”>
DIAL Not used
SMS The SMS message
TEXT Text message
EMAIL E-mail message
OUT A sequence of “101..“ to be transferred to the addressed
output. Each state will be ta long.
CMD Not used
TRANS Not used
