6618-3202 55
<norm>
Normal inactivated state of the output as well as the source controlling the output.
0 = NO Output not used
1 = I/O operation Operation controlled by remote I/O Transparent or Out
2 Reserved
3 = DCD Output will be controlled by DCD. An active DCD will activate the
output.
4 = DTR Output will be controlled by DTR. An active DTR will activate the
output
31 = DCD PSTN Output is controlled by DCD on the PSTN interface
32 = DCD LL Output is controlled by DCD on the Leased Line interface
Note! If LEVEL trigged input is programmed, all defined entries will be trigged.
Command example Possible responses Note
AT*WIOP = 50,100,1,1,3 OK Command valid and accepted
AT*WIOP=50,100,2,1,3 OK Change input type to be pulse
trigged
AT*WIOP? *WIOP : TA = 50, TP = 100, List parameters
TYPE = 2, TRIG = 1, NORM = 3
OK
AT*WIOP=? *WIOP: (1-255), (1-255), List command parameters
(0-4, 31, 32), (0-6), (0-4, 31, 32)
OK
ERROR Otherwise
S register: None
