4. Insert the sealing insert into the gland body and then attach the clamping nut to complete the
cable solution.
Using the Cable Gland
Using the Conduit Gland
NOTE:

Ensure that the clamping nut is tightly attached to the gland body.

When using the naked cable with cable gland solution, be sure to pull enough length of
the cable to connect to the camera later. Once the clamping nut is tightened, the cable
cannot be pulled anymore.
