AES
Pair nL, Pair nR
Shows whether the AES input contains a valid AES signal or not. For each
individual entry, if the input is a valid AES signal the front panel will show
one of the following possible audio options:
•
PCM
•
DolbyE
•
DolbyD
•
Non-PCM
If the input is not a valid AES signal the front panel with display “Unlocked”.
The status is shown for the left (L) and right (R) of each of the 16 channel
pairs.
Clocks
74 MHz Clk
Shows whether the internal 74 MHz clock has successfully locked. The front
panel will show either “Locked” or “Unlocked”.
54 MHz Clk
Shows whether the internal 54 MHz clock has successfully locked. The front
panel will show either “Locked” or “Unlocked”.
27 MHz Clk
Shows whether the internal 27 MHz clock has successfully locked. The front
panel will show either “Locked” or “Unlocked”.
.
