Imagestore 750 User Manual
Front Panel Operations
Miranda Technologies Inc.
Page 155
SYS 3.3V
Displays the voltage of the +3.3V supply rail.
SYS 2.5V
Displays the voltage of the +2.5V supply rail.
SYS 1.8V
Displays the voltage of the +1.8V supply rail.
SYS 1.2V
Displays the voltage of the +1.2V supply rail.
DVE 12V
Displays the voltage of the 12V supply rail on the DVE card.
DVE 2.5V
Displays the voltage of the 2.5V supply rail on the DVE card.
DVE 1.8V
Displays the voltage of the 1.8V supply rail on the DVE card.
DVE 1.2V
Displays the voltage of the 1.2V supply rail on the DVE card.
PSU A
Displays status of power supply A as OK or FAIL.
PSU B
Displays status of power supply B as OK or FAIL.
